Forklift Fork Extension
Forklift Fork Extensions - Forklift extensions are a terrific choice when there is a need to reach further than your existing forks will allow. In certain cases when you have a load that exceeds more than can be safely lifted on your lift truck, an extension can help you complete your task safely.
Increasing Forklift Output
Forklift extensions provide the extra support and capacity needed whenever picking up long pallets, containers or extremely heavy loads. Furthermore, the extensions add more length to the forks which enables the one operating it to be able to reach greater distances. Utilizing lift truck extensions truly saves a business the requirement to purchase individual equipment to be able to complete the job. This could save possibly thousands of dollars while adding more efficiency and productivity options using the machine you already have.
A lot of the fork extensions will just slip overtop of the forklift blades. Extensions could be obtained to be able to fit forks with widths from four to six inches. It is really important that you gauge the extensions to be sure of a correct fit. Knowing that extensions have an inside width that is half an inch wider than the size stated is vital to making sure the correct fit. When buying your extension size, make certain it is equal to your fork's width. For example, if you have blades which are 6 inches wide, you would use an extension that is 6 inches wide.
OSHA Standards
OSHA standards for safety have a regulation length for fork extensions. Based on this particular guideline, blade extensions cannot be longer than 50 percent of the original blade length. Abiding by these rules would help to sustain a safe operation. A yellow powder coat finish is added to the metal lift truck extensions so as to avoid corrosion. The two most common sizes for forklift extensions in the business are 60" and 72", even if, various lengths are available.
Securing Mechanism
Securing mechanisms are available in two options. The first choice connects the extensions onto the lift truck with a single pull pin. This is the quick release method. The second and safer choice is the safety loop which is welded on and provides a more secure attachment of the extension. The lift truck extensions are existing either tapered or non-tapered for most pallet and container loads. Triangular extensions are used when transporting cylinder loads.
Cylinder Loads
Loads that have coils, pipes or drums are considered to be cylinder loads. Extensions for cylinder loads are also made of steel. They are made to fit blades up to 2" thick and which are 4" to 5" in width. Attached in place utilizing a locking bar, they slide off and on easily. Triangular extensions range in length from fifty four to sixty inches.
Safety Measures
It is at all times a good idea to utilize safety precautions whenever handling whichever type of industrial equipment and forklift extensions are no different. Checking your lift truck extensions before use is also a great routine to get into. When the extensions have been placed onto the forklift, the securing mechanism should be inspected also. Personal injury or destruction to the load could occur if the extensions were to become unfastened and fall off. Adhering OSHA regulations will even help in order to guarantee the safety of the one operating it and individuals working close by.
